Unit: mm
9.8 Newton(N) = 1kg = 2.2LBS
| Model No. | 1) Stroke (A) |
2) Stroke (A*) |
Extended Length (B) |
3)4) Tension Force FZ (N) |
3)5) Compression FD (N) |
Weight (g) | Remark |
| HD24C-348-C1920-650N | 80 | 130 | 348 | <100 | 650 | ||
| HD24C-348-C1920-1500N | <100 | 1500 | |||||
| HD24C-348-C1920-3000N | <100 | 3000 | |||||
| HD24C-464-C1920-650N | 120 | 188 | 464 | <100 | 650 | ||
| HD24C-464-C1920-1500N | <100 | 1500 | |||||
| HD24C-464-C1920-3000N | <100 | 3000 | |||||
| HD24C-698-C1920-650N | 200 | 305 | 698 | <100 | 650 | ||
| HD24C-698-C1920-1500N | <100 | 1500 | |||||
| HD24C-698-C1920-3000N | <100 | 3000 |
