Unit:mm
9.8 Ncwton(N) = 1kg = 2.2LBS
| Model No. | 1) Stroke (A) |
2) Stroke (A*) |
Extended Length (B) |
3)4) Tension Force FZ (N) |
3)5) Compression FD (N) |
Weight (g) | Remark |
| HD24E-271-C1920-650N | 80 | 80 | 271 | 650 | <100 | ||
| HD24E-271-C1920-1500N | 1500 | <100 | |||||
| HD24E-271-C1920-5000N | 5000 | <100 | |||||
| HD24E-360-C1920-650N | 120 | 120 | 360 | 650 | <100 | ||
| HD24E-360-C1920-1500N | 1500 | <100 | |||||
| HD24E-360-C1920-5000N | 5000 | <100 | |||||
| HD24E-538-C1920-650N | 200 | 200 | 538 | 650 | <100 | ||
| HD24E-538-C1920-1500N | 1500 | <100 | |||||
| HD24E-538-C1920-5000N | 5000 | <100 |
